Plus de références
Riferimento
Peso netto (kg)
Ø est (mm)
Pour tube Ø ext.
RPY ET0404
RPY ET0505
RPY ET0606
RPY ET0808
RPY ET1010
RPY ET1212
RPY ET1414
RPY ET1616
Dimensioni
Riferimento
A (mm)
B (mm)
C (mm)
D (mm)
E (mm)
RPY ET0404
34
20
10.5
10
RPY ET0505
37
25.6
13
12.8
RPY ET0606
37
25.6
13
12.8
RPY ET0808
37.6
27.6
14.5
13.8
RPY ET1010
50.6
33.6
18
16.8
RPY ET1212
53.1
39.6
20
19.8
RPY ET1414
54.6
45.4
23.3
22.7
RPY ET1616
56.6
49
24.5
24.5
| Riferimento | Peso netto (kg) | Ø est (mm) | Pour tube Ø ext. | 3D |
|---|---|---|---|---|
| RPY ET0404 | 0,005 Kg | 4 mm | 4 mm | |
| RPY ET0505 | 0,009 Kg | 5 mm | 5 mm | |
| RPY ET0606 | 0.008 Kg | 6 mm | 6 mm | |
| RPY ET0808 | 0.010 Kg | 8 mm | 8 mm | |
| RPY ET1010 | 0,018 Kg | 10 mm | 10 mm | |
| RPY ET1212 | 0,026 Kg | 12 mm | 12 mm | |
| RPY ET1414 | 0,033 Kg | 14 mm | 14 mm | |
| RPY ET1616 | 0,032 Kg | 16 mm | 16 mm |
Dimensioni
| Riferimento | A mm | B mm | D mm | E mm |
|---|---|---|---|---|
| RPY ET0404 | 34 | 20 | 10.5 | 10 |
| RPY ET0505 | 37 | 25.6 | 13 | 12.8 |
| RPY ET0606 | 37 | 25.6 | 13 | 12.8 |
| RPY ET0808 | 37.6 | 27.6 | 14.5 | 13.8 |
| RPY ET1010 | 50.6 | 33.6 | 18 | 16.8 |
| RPY ET1212 | 53.1 | 39.6 | 20 | 19.8 |
| RPY ET1414 | 54.6 | 45.4 | 23.3 | 22.7 |
| RPY ET1616 | 56.6 | 49 | 24.5 | 24.5 |
